AKN142061U

METERED RACK PDU – INPUT

The Apislogik Input Metered PDU can monitor input parameters in real-time, such as current, voltage, frequency, power factor, power load, energy measurement, temperature, and humidity. The voltage and current accuracy is ±1%. The power and energy accuracy is ±2%. The measured data can be transmitted via the network port.

Inventory Count: 500

In stock

$952.00

For special pricing on bulk orders or to inquire about custom orders, please contact our sales team for support. Reach out to us here to get started!

Features

SPECIFICATIONS
ManufacturerApislogik
CategoriesPDU
Manufacturer Product NumberAKN142061U
Full DescriptionMETERED RACK PDU – INPUT - 208V - 3ph+N+G - 20A - C13(36) C19(6) 5-20R(2)
SeriesAKN
TypeMETERED RACK PDU – INPUT
Voltage Input208v
Voltage Output208V
Phase Configuration3ph+N+G
Current - Max20A
kW Rated5.8kW
kW Max7.2kW
Connector - AC InputNEMA L21-20P
Connector - AC OutputC13(36) C19(6) 5-20R(2)
C1336
C196
C39N/A
5-20R2
Part StatusACTIVE
ConditionNew
Mounting TypeRACK, VERTICAL
Cord Length9.8’ (3m)
Warranty3-years
Approval AgencycUL, FCC, UL
Region UtilizedNORTH AMERICA
Price$952

* Product Characteristics subject to change without prior notice.

* Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
